6082 aluminum alloy is a heat treatable alloy, which can be strengthened by heat treatment and quenching process. 6082 aluminum is usually used in the form of extrusions, sheets or plates, and is available in a variety of sizes and thicknesses to suit different Applications.
6082 aluminum plate possesses high strength, corrosion resistance, good machinability, weldability and anodizing properties, which make it a popular choice for construction applications. 6082 aluminum plate is commonly used in structural applications including the aerospace, transportation and construction industries.
Common Mechanical Properties and Tempers of 6082 Aluminum Sheet
| Material | Thickness (mm) | Tensile Strength (N/mm²) min | Yield Strength (N/mm²) min | Elongation on 50mm % (min) |
| 6082 Alloy Sheet – T6 | 0.2 – 3.0 | 295 | 255 | 8 |
| 3.0 – 6.0 | 295 | 240 | 8 | |
| 6.0 – 25.00 | 295 | 240 | 8 |
It is worth noting that these values can be further improved through the use of heat treatment processes, such as annealing, quenching, and precipitation hardening. Additionally, the thickness of the plate can also affect its mechanical properties, with thicker plates generally having higher strength but lower ductility.
6082 Aluminum Plate Informations
- Machinability:It has high machinability.
- Welding:This aluminum sheet has high weldability.
- Heat Treatment:It can be heat treated.
- Industries:It is commonly used in the construction and automotive industries.
- Applications:Typical applications of this aluminum are trusses, cranes, bridges, beer kegs, milk churns, and automotive parts.
- Advantages Disadvantages:This aluminum material is lightweight, easily formable, has high electrical and thermal conductivity, and can be strengthened by heat treatment.
6082 Aluminum Plate Specifications
| Mechanical Property | Value |
|---|---|
| Thickness | 6mm to 200mm |
| Width | up to 2500mm |
| Length | up to 6000mm or as per customer requirements |
| Temper | T6, T651, T6511, T6512 |
| Surface treatment | mill finish, brushed, anodized, polished, etc. |
| Standard | EN 485/573, ASTM B209, AMS-QQ-A-250/12, DIN 3.2315 |
Haomei Aluminum Supply Aluminium Alloy 6082
6082 T6 Aluminium Plate
6082 t6 aluminum sheet is the most common type of 6082 aluminum sheet, providing the highest strength and hardness in the 6082 state.
Processing process : 6082 aluminum plate undergoes solution heat treatment and then artificial aging treatment.
- Features : High strength, excellent processability and good corrosion resistance.
- Applications : 6082 t6 aluminum sheet is often used in structural and engineering applications requiring high strength and durability.
| Mechanical Property | Value |
|---|---|
| Tensile strength | 330 MPa |
| Yield strength | 290 MPa |
| Elongation | 0.1 |
| Hardness | 95 Brinell |
| Fatigue strength | 145 MPa |
6082 t651 Aluminium Plate
Compared with 6082 t6 aluminum plate, 6082 t651 aluminum plate has improved dimensional stability and reduces the risk of deformation during processing.
- Processing : T651 This temper involves drawing the sheet after a solution heat treatment and aging process.
- Features : high strength, good processability and corrosion resistance
- Application : Suitable for applications that do not require high surface quality but require high strength.
The surface of 6082-T651 aluminum plate usually requires surface treatment, such as grinding, polishing, chemical treatment, etc., to obtain the required surface quality. During processing, since the surface has not been specially treated, special attention should be paid to prevent scratches and scratches on the surface, so as not to affect the surface quality.
6082 t6511 Aluminium Plate
6082 t6511 aluminum plate is an improved version of 6082 t651 aluminum plate, the plate is stretched during processing to reduce residual stress and improve flatness.
- Processing : This is an improved version of the T651 state, the surface has been specially treated.
- Features : It has good surface quality and generally does not require additional surface treatment.
- Application : Suitable for applications requiring high surface quality.
The surface of the 6082-T6511 aluminum plate has been specially treated, and the 6082-T6511 aluminum plate has good processing performance and surface quality during processing
6082 t4 Aluminium Plate
6082 T4 aluminum plate has higher formability and lower strength than 6082 T6 aluminum plate.
- Processing : T4 This temper involves solution heat treatment followed by natural aging.
- Features : better formability, but lower strength.
- Applications : Typically used in applications requiring good formability, such as automotive panels and aerospace parts.
Aluminium Tooling Plate 6082
Aluminum tooling plate 6082 is a type of aluminum plate that is specifically designed for use in tooling applications. It is typically made from the 6082 aluminum alloy, which contains magnesium and silicon as its main alloying elements.
The main characteristics of aluminum tooling plate 6082 include :
- High strength and rigidity : Aluminum tooling plate 6082 has excellent strength and stiffness, making it ideal for use in tooling applications that require precision and durability.
- Dimensional stability : Aluminum tooling plate 6082 has very low levels of deformation, even under heavy loads or when subjected to changes in temperature.
- Machinability : Aluminum tooling plate 6082 is easy to machine and work with, which makes it a popular choice for tooling applications that require precise machining.
- Corrosion resistance : Aluminum tooling plate 6082 is highly resistant to corrosion, making it suitable for use in environments where exposure to moisture or other corrosive elements is a concern.
Aluminum tooling plate 6082 is available in a range of thicknesses and sizes, and can be supplied in both T6 and T651 temper conditions. It is commonly used in a variety of tooling applications, including injection molds, blow molds, vacuum forming tools, and jigs and fixtures.
6082 Aluminum Plate Chemical Composition Limits
| Mechanical Property | Value |
|---|---|
| Aluminum (Al) | 96.8% to 98.5% |
| Magnesium (Mg) | 0.6% to 1.2% |
| Silicon (Si) | 0.4% to 1% |
| Iron (Fe) | 0.0% to 0.5% |
| Manganese (Mn) | 0.0% to 0.1% |
| Chromium (Cr) | 0.05% to 0.25% |
| Zinc (Zn) | 0.0% to 0.2% |
| Titanium (Ti) | 0.0% to 0.1% |
| Other elements | each <0.05 |
Physical Properties of 6082 Aluminium Plate
| Mechanical Property | Value |
|---|---|
| Density | 2.70 g/cm³ (0.0975 lb/in3) |
| Melting point | 555°C (1031°F) |
| Thermal conductivity | 180 W/m-K (1050 BTU-in/hr-ft²-°F) |
| Electrical conductivity | 34.9 MS/m (219% IACS) |
| Coefficient of thermal expansion | 23.8 x 10^-6/K (13.2 x 10^-6/°F) |
Aluminum alloy 6082 also has a relatively low modulus of elasticity compared to other metals, which means it is more flexible and less stiff. Additionally, it has good corrosion resistance properties, particularly when compared to other aluminum alloys, which makes it well-suited for use in marine environments or other corrosive environments.
What is 6082 Aluminum Plate Used for?
6082 aluminum is a versatile aluminum alloy that has a wide range of applications across various industries. Some common uses for 6082 aluminum include :
- Aerospace industry : 6082 aluminum is used to manufacture components for aircraft and spacecraft, including fuselage frames, wing skins, and landing gear.
- Transportation industry : 6082 aluminum is used to make automotive parts, including wheels, chassis components, and engine parts.
- Construction industry : 6082 aluminum is used in the construction of bridges, buildings, and other structures, thanks to its high strength, corrosion resistance, and ease of fabrication.
- Marine industry : 6082 aluminum is commonly used in the construction of boats, ships, and other marine vessels, due to its excellent corrosion resistance and lightweight properties.
- Tooling industry : 6082 aluminum tooling plate is widely used in the production of injection molds, blow molds, and other tooling components, thanks to its high strength, dimensional stability, and machinability.
- Sporting goods industry : 6082 aluminum is used to make a variety of sporting goods, including bicycles, snowboards, and ski poles, due to its lightweight and high strength.
What is 6082 Aluminium Plate Equivalent to?
The 6082 alloy is also known by several different designations, depending on the standard or specification being used. Some of the most common designations for this alloy include :
- AA6082 : This is the Aluminum Association (AA) designation for the 6082 alloy.
- EN AW-6082 : This is the European standard designation for the 6082 alloy, as defined by the European Committee for Standardization (CEN).
- ISO AlSi1MgMn : This is the International Organization for Standardization (ISO) designation for the 6082 alloy.
- UNS A96082 : This is the Unified Numbering System (UNS) designation for the 6082 alloy, as defined by the American Society for Testing and Materials (ASTM).
What is the Difference between Aluminium 6061 and 6082?
Both 6082 and 6061 aluminum have high strength and good machinability.
NO1. In terms of mechanical properties :
- The tensile strength and yield strength of 6082 aluminum are higher than those of 6061 aluminum.
- 6061 aluminum has better corrosion resistance than 6082 aluminum. (especially in marine environments)
NO2. In terms of application :
- 6061 aluminum is commonly used in structural applications such as aircraft and marine components, bicycle frames and automotive components.
- 6082 aluminum is commonly used in applications requiring high strength and good corrosion resistance, such as truck and trailer components, marine and offshore equipment, and pressure vessels.
6082 Aluminum Plate Supplier
Haomei Aluminum is a professional supplier of aluminum sheets, we have high-quality raw materials, advanced production technology and strict quality control system. The 6082 aluminum plate produced by the company ensures stable performance, high dimensional accuracy and good surface quality of the aluminum plate.
The dimensional accuracy of the 6082 aluminum plate meets the requirements of relevant standards to ensure the accuracy and stability of the aluminum plate during processing and installation. In addition, anti-rust, anti-oxidation and other treatments can be carried out on the aluminum plate.
