1100 aluminum coil, due to its excellent formability, versatility, and workability, is suitable for a wide range of applications from decorative items and electronics to food and beverage containers.
Common tempers of 1100 aluminum coil include 1100 H18 aluminum coil, 1100 H14 aluminum coil, and 1100 O aluminum coil.
1100 O aluminum coil is suitable for applications that require bending, spinning, drawing, stamping, and roll forming. It has good thermal conductivity and is often used in heat exchangers and radiators in electrical applications.
1100 aluminum coil is easy to weld, has high conductivity, good thermal conductivity, and good plasticity, and can easily withstand various pressures. It has high strength and very good cutting performance. The 1100 aluminum coil is very soft and ductile, and has very durable performance.
Information about 1100 Aluminum Coil
| Property | Details |
| Aging Resistance | This material does not age, but it may oxidize in extremely humid conditions and/or when exposed to extreme temperatures (hot and cold). |
| Annealing | Annealing may be required after cold working. The material is heated to 650°F and then air-cooled. |
| Applications | Aluminum foil products, cookware, heat exchangers, wire, nameplates, conductors, decorations |
| ASTM Standard | B209 |
| Processing | High ductility of 1100 aluminum coil makes it one of the most easily processed alloys. |
| Finish | Standard finish |
| Heat Treatment | 1100 aluminum coil is not heat treatable. |
| Weldability | Aluminum coil 1100 is weldable using various welding techniques, especially Tungsten Inert Gas (TIG) welding, showing satisfactory weldability. |
| Other Physical Properties | Characteristics: Electrical conductivity is 53% of copper. |
| Key Design Features | This alloy contains at least 99.0% pure aluminum, with excellent forming and processing capabilities. |
| Thickness | 0.0005 to 0.064 inches |
| Width | 0.375 to 60 inches |
1100 Aluminum Alloy Material Characteristics
1. Excellent Formability
1100 is one of the commercially purest aluminum alloys, known for its high formability despite its low strength. It is very soft in annealed conditions, making it ideal for manufacturing applications involving spinning, bending, stamping, roll forming, and stretching.
2. Cold Work Hardenability
Although 1100 aluminum cannot be heat treated, it can be hardened through cold working processes to increase hardness and even strength at sub-zero temperatures. We can provide industrial-grade aluminum coils, foils, sheets, and wires in the required annealed state.
3. Thermal Conductivity
1100 aluminum coil exhibits excellent thermal and electrical conductivity. Due to its thermal properties, it is widely used in manufacturing heat exchanger components such as heat sinks and radiators used in electronic devices.
4. Good Corrosion Resistance
The corrosion resistance of 1100 aluminum makes it suitable for producing weather-resistant heavy-duty structures and components. These include tank fittings in pipeline applications, components for railway vehicles and ships, building materials, and even aircraft gun carriage components.
Advantages of 1100 Aluminum Coil
1100 aluminum coil offers a range of advantages, including:
- Excellent corrosion resistance
- High electrical conductivity
- Outstanding formability
- Excellent machinability and weldability
Specifications of the 1100 Aluminum Coil
| Temper | F, O, H14, H16, H18, H19, H22, H24, H26, H28 |
| Thickness (mm) | 0.014-0.4 |
| Width (mm) | 40-1600 |
| Roll ID/OD (mm) | Customized |
Applications of The 1100 Aluminum Coil
| Industry | Application | Reason for Choosing 1100 Aluminum Coil |
| Cookware | 1100 aluminum coil cooking utensils | Excellent corrosion resistance, good thermal conductivity |
| Industrial | 1100 aluminum coil heat sinks | High thermal conductivity, good corrosion resistance |
| 1100 aluminum coil caps | Easy to form and fabricate, good corrosion resistance | |
| 1100 aluminum coil printing coils | Good corrosion resistance, ease of forming | |
| 1100 aluminum coil building materials | High formability, excellent corrosion resistance | |
| 1100 aluminum coil heat exchanger components | High thermal conductivity, corrosion resistance | |
| Manufacturing | 1100 aluminum coil deep-draw stamping products | Excellent ductility, ease of forming |
| 1100 aluminum coil heavy-duty structures | Good corrosion resistance, sufficient strength | |
| 1100 aluminum coil truck and marine components | Good corrosion resistance, lightweight | |
| 1100 aluminum coil railroad cars | Corrosion resistance, sufficient strength | |
| 1100 aluminum coil furniture | Ease of forming, good corrosion resistance | |
| 1100 aluminum coil tank fittings | Corrosion resistance, ease of fabrication | |
| 1100 aluminum coil general structural applications | Corrosion resistance, sufficient strength | |
| 1100 aluminum coil high-pressure applications | Good formability, sufficient strength | |
| 1100 aluminum coil wire products | Good corrosion resistance, electrical conductivity | |
| 1100 aluminum coil pipelines | Corrosion resistance, ease of forming | |
| HVAC | 1100 aluminum coil fin stock and heat exchanger fins | High thermal conductivity, corrosion resistance |
| Consumer Products | 1100 aluminum coil spun hollowware | Good formability, excellent corrosion resistance |
| 1100 aluminum coil dials and nameplates | Ease of fabrication, good corrosion resistance, aesthetic appeal |
1100 Aluminum Coil Application Data Sheet
| Application | Example of Application | Common Thickness (mm) |
| 1100 aluminum coil cooking utensils | 1100 aluminum coil for pots | 0.5 - 2.0 |
| 1100 aluminum coil for frying pans | 0.5 - 2.0 | |
| 1100 aluminum coil for baking trays | 0.5 - 2.0 | |
| 1100 aluminum coil heat sinks | 1100 aluminum coil for electronic equipment heat sinks | 0.2 - 1.0 |
| 1100 aluminum coil for LED heat sinks | 0.2 - 1.0 | |
| 1100 aluminum coil caps | 1100 aluminum coil for can lids | 0.2 - 0.5 |
| 1100 aluminum coil for bottle caps | 0.2 - 0.5 | |
| 1100 aluminum coil printing coils | 1100 aluminum coil for printing plates | 0.1 - 0.5 |
| 1100 aluminum coil for printing rollers | 0.1 - 0.5 | |
| 1100 aluminum coil building materials | 1100 aluminum coil for roofing sheets | 0.5 - 1.5 |
| 1100 aluminum coil for wall panels | 0.5 - 1.5 | |
| 1100 aluminum coil heat exchanger components | 1100 aluminum coil for air conditioner heat exchangers | 0.2 - 1.0 |
| 1100 aluminum coil for automotive radiators | 0.2 - 1.0 | |
| 1100 aluminum coil deep-draw stamping products | 1100 aluminum coil for automotive parts | 0.5 - 2.0 |
| 1100 aluminum coil for household appliance casings | 0.5 - 2.0 | |
| 1100 aluminum coil heavy-duty structures | 1100 aluminum coil for industrial equipment structures | 1.0 - 5.0 |
| 1100 aluminum coil for building support structures | 1.0 - 5.0 | |
| 1100 aluminum coil truck and marine components | 1100 aluminum coil for truck panels | 1.0 - 3.0 |
| 1100 aluminum coil for marine hulls | 1.0 - 3.0 | |
| 1100 aluminum coil railroad cars | 1100 aluminum coil for railway carriages | 1.0 - 3.0 |
| 1100 aluminum coil for railway components | 1.0 - 3.0 | |
| 1100 aluminum coil furniture | 1100 aluminum coil for metal furniture | 0.5 - 2.0 |
| 1100 aluminum coil for furniture veneers | 0.5 - 2.0 | |
| 1100 aluminum coil tank fittings | 1100 aluminum coil for tank lids | 0.2 - 0.5 |
| 1100 aluminum coil for tank bottoms | 0.2 - 0.5 | |
| 1100 aluminum coil general structural applications | 1100 aluminum coil for industrial frames | 1.0 - 5.0 |
| 1100 aluminum coil for supports | 1.0 - 5.0 | |
| 1100 aluminum coil high-pressure applications | 1100 aluminum coil for high-pressure pipelines | 1.0 - 3.0 |
| 1100 aluminum coil for high-pressure vessels | 1.0 - 3.0 | |
| 1100 aluminum coil wire products | 1100 aluminum coil for cables | 0.1 - 0.5 |
| 1100 aluminum coil for wire sheathing | 0.1 - 0.5 | |
| 1100 aluminum coil pipelines | 1100 aluminum coil for industrial pipelines | 0.5 - 2.0 |
| 1100 aluminum coil for water pipes | 0.5 - 2.0 | |
| 1100 aluminum coil fin stock and heat exchanger fins | 1100 aluminum coil for air conditioner fins | 0.1 - 0.5 |
| 1100 aluminum coil for condenser fins | 0.1 - 0.5 | |
| 1100 aluminum coil spun hollowware | 1100 aluminum coil for kitchen utensils | 0.5 - 2.0 |
| 1100 aluminum coil for decorative items | 0.5 - 2.0 | |
| 1100 aluminum coil dials and nameplates | 1100 aluminum coil for mechanical dials | 0.2 - 0.5 |
| 1100 aluminum coil for brand nameplates | 0.2 - 0.5 |
Disadvantages of 1100 Aluminum Coil
1100 aluminum coil is not suitable for high-strength or high-pressure applications due to its low tensile strength and softness.
Mechanical Property Limits of 1100 Aluminum Coil
| Temper | Specified Thickness(in) | Tensile Strength - KSI | Elongationin 2 inches % | |||
| Ultimate | Yield | |||||
| Min | Max | Min | Max | |||
| 1100 H12 | 0.017 - 0.019 | 14 | 19 | 11 | - | 3 |
| 1100 H12 | 0.020 - 0.031 | 14 | 19 | 11 | - | 4 |
| 1100 H12 | 0.032 - 0.050 | 14 | 19 | 11 | - | 6 |
| 1100 H12 | 0.051 - 0.113 | 14 | 19 | 11 | - | 8 |
| 1100 H12 | 0.114 - 0.250 | 14 | 19 | 11 | - | 9 |
| 1100 H14 | 0.009 - 0.012 | 16 | 21 | 14 | - | 1 |
| 1100 H14 | 0.013 - 0.019 | 16 | 21 | 14 | - | 2 |
| 1100 H14 | 0.020 - 0.031 | 16 | 21 | 14 | - | 3 |
| 1100 H14 | 0.032 - 0.050 | 16 | 21 | 14 | - | 4 |
| 1100 H14 | 0.051 - 0.113 | 16 | 21 | 14 | - | 5 |
| 1100 H14 | 0.114 - 0.250 | 16 | 21 | 14 | - | 6 |
| 1100 H16 | 0.006 - 0.019 | 19 | 24 | 17 | - | 1 |
| 1100 H16 | 0.020 - 0.031 | 19 | 24 | 17 | - | 2 |
| 1100 H16 | 0.032 - 0.050 | 19 | 24 | 17 | - | 3 |
| 1100 H16 | 0.051 - 0.162 | 19 | 24 | 17 | - | 4 |
| 1100 H18 | 0.006 - 0.019 | 22 | - | - | - | 1 |
| 1100 H18 | 0.020 - 0.031 | 22 | - | - | - | 2 |
| 1100 H18 | 0.032 - 0.050 | 22 | - | - | - | 3 |
| 1100 H18 | 0.051 - 0.128 | 22 | - | - | - | 4 |
| 1100 H19 | 0.006 - 0.063 | 24 | - | - | - | 1 |
| 1100 O | 0.006 - 0.019 | 11 | 15.5 | 3.5 | - | 15 |
| 1100 O | 0.020 - 0.031 | 11 | 15.5 | 3.5 | - | 20 |
| 1100 O | 0.032 - 0.050 | 11 | 15.5 | 3.5 | - | 25 |
| 1100 O | 0.051 - 0.249 | 11 | 15.5 | 3.5 | - | 30 |
Chemical Composition of 1100 Aluminum Coil
| Si Silicon | Fe Iron | Cu Copper | Mn Manganese | Mg Magnesium | Cr Chromium | Ni Nickel | Zn Zinc | Ti Titanium | Others Each | Total | Total Aluminum Min |
| 0.95 | - | 0.05 - 0.2 | 0.05 | - | - | - | 0.1 | - | 0.05 | - | 99 |
