Marine Grade Aluminum Plate 5083
Marine Grade Aluminum Plate 5083 is a high strength, non-heat treatable alloy ideal for use in marine environments. This alloy is often used in hulls, decks and other marine structures due to its excellent corrosion resistance and high strength-to-weight ratio.
Due to its good weldability, 5083 marine aluminum plate can be easily manufactured into a strong and light structure. This is very important to boat builders and makes 5083 aluminum alloy a popular choice for marine applications.
Top 10 Reasons to Choose 5083 Marine Aluminum Plate
Marine Grade Aluminum 5083 is a popular choice for a variety of marine and offshore applications due to its excellent properties and performance in marine environments.
1. Corrosion Resistance
Marine environments are harsh and corrosive, with exposure to saltwater and other corrosive elements. Aluminum 5083 offers exceptional corrosion resistance, making it well-suited for applications where rust and corrosion can be a significant concern.
2. High Strength
Aluminum 5083 has a high tensile strength, which means it can withstand significant loads and stresses. This makes it suitable for structural components in marine applications, such as boat hulls, superstructures, and offshore platforms.
3. Lightweight
Aluminum is much lighter than steel, which can be a crucial factor in marine applications where weight savings are important. The lightweight nature of 5083 aluminum helps improve fuel efficiency and buoyancy, making it a preferred choice for boat construction.
4. Weldability
Aluminum 5083 is easily weldable using common welding techniques, which is essential for fabricating complex structures and repairing marine components. This weldability ensures ease of construction and maintenance.
5. Formability
It can be easily formed and fabricated into various shapes and sizes, allowing for design flexibility and customization in marine applications.
6. Low-Temperature Performance
Marine environments can experience low temperatures, and Aluminum 5083 maintains its excellent mechanical properties even at sub-zero temperatures, which is important for cold-water applications.
7. Resistance to Fracture and Crack Propagation
Aluminum 5083 has good resistance to fracture and crack propagation, which is crucial for safety in marine structures.
8. Non-Toxic and Non-Magnetic
Aluminum is non-toxic, so it doesn't harm marine life, and it is also non-magnetic, which is beneficial for certain electronic and navigational equipment on vessels.
9. Longevity
Aluminum 5083 has a long service life, particularly when properly maintained. Its resistance to corrosion means it can withstand the harsh marine environment for many years.
10. Recyclability
Aluminum is highly recyclable, making it an environmentally friendly choice. Recycling aluminum requires significantly less energy compared to producing it from raw materials, reducing the carbon footprint of marine operations.
Marine Grade Aluminum 5083 is a versatile and durable material that offers a combination of strength, corrosion resistance, lightweight properties, and ease of fabrication, making it an excellent choice for various marine and offshore applications, including boat building, ship construction, and offshore platform components.
Marine Grade Aluminum 5083 Plate Specifications
Marine grade aluminum 5083 sheet has excellent corrosion resistance and high strength to weight ratio and is commonly used in marine applications. Here are some common specifications for marine grade aluminum 5083 sheet :
- Thickness : Marine grade 5083 aluminum sheet typically ranges in thickness from 0.5mm to 50mm.
- Widths : The width of marine grade 5083 aluminum sheet varies by supplier and application, but common widths include 1000mm, 1250mm and 1500mm.
- Lengths : Lengths of marine grade 5083 aluminum sheet may vary by supplier and application, but common lengths include 2000mm, 2500mm and 3000mm.
- Condition : Marine grade aluminum 5083 sheet is usually available in H116, H321 and H111 tempers. The H116 temper is a strain hardened and stable state, while the H321 temper is a strain hardened and partially annealed stable state. The H111 state is the annealed state.
- Standards : Marine grade 5083 aluminum sheet can be manufactured to various international standards such as ASTM B209, EN 485-2 and JIS H4000.
It is important to note that exact specifications for marine grade 5083 aluminum sheet may vary depending on the supplier and application requirements. It is best to consult a trusted supplier or manufacturer for more detailed specifications.
相关产品
Quality of Haomei Aluminum 5083 Ship Plate
The quality testing standards for 5083 ship plates generally include the following aspects :
- Chemical composition : The chemical composition of aluminum alloy 5083 is tested to meet the standard.
- Mechanical properties : The tensile strength, yield strength, elongation and other mechanical properties of 5083 ship plate meet the standards.
- Corrosion performance : 5083 ship plate has passed the immersion test, salt spray corrosion test, corrosion potential test and other indicators of corrosion resistance meet the standards.
- Surface quality inspection : whether the surface of the ship plate is smooth, free of cracks, and whether the oxide film is uniform, etc.
5083 Aluminum Plate Application for Marine
The structures that can be made of 5083 aluminum alloy on ships include hulls, decks, bulkheads, ship superstructures and other parts. The following is a detailed introduction of the states and specifications of 5083 alloys that can be used for each structure :
5083 Aluminum Plate for Hull
The hull is the most important part of the ship, and the use of 5083 aluminum alloy can effectively improve the strength and corrosion resistance of the hull.
The commonly used state is H116. The 5083 alloy in this state has high strength and good corrosion resistance after stress processing and stabilization treatment.
Common specifications are thickness between 1mm and 50mm, width between 1000mm and 1500mm, and length between 2000mm and 6000mm.
5083 Aluminum Plate for Deck
The deck is the platform on the ship. The use of 5083 aluminum alloy can reduce the weight of the ship and increase the load capacity of the ship.
The H116 status is also used,
Common specifications are thickness between 1mm and 50mm, width between 1000mm and 1500mm, and length between 2000mm and 6000mm.
5083 Aluminum Plate for Partition
Bulkheads are dividing walls on ships used to isolate different areas and to increase the strength of the hull structure.
The state of the 5083 aluminum alloy used is also H116,
Common specifications are thickness between 1mm and 50mm, width between 1000mm and 1500mm, and length between 2000mm and 6000mm.
5083 Aluminum Plate for Ship Structure
Ship structure refers to the ship structure located above the deck, such as cabins, deck houses, navigation bridges and other parts.
The state of the 5083 aluminum alloy used can be H116 or H321,
The common specifications are the same as the structure mentioned above, the thickness is between 1mm and 50mm, the width is between 1000mm and 1500mm, and the length is between 2000mm and 6000mm.
Marine Grade Aluminum 5083 Properties
- Machinability : Marine grade aluminum 5083 has moderate to low machinability due to its high strength and hardness. Machining this alloy may require special tools and techniques.
- Heat Treatability : Alloy 5083 is a non-heat treatable alloy, meaning it cannot be strengthened by heat treatment processes such as annealing, quenching, or tempering.
- Anodizing : This alloy can be anodized to create a hard, durable, and corrosion-resistant surface suitable for decorative or protective purposes.
Chemical composition of 5083 marine grade aluminum plate sheet
| Element | Composition % |
| Al | REM |
| Si | ≤0.4 |
| Cu | ≤0.10 |
| Mg | 4.0-4.9 |
| Zn | ≤0.25 |
| Mn | 0.40-1.0 |
| Ti | ≤0.15 |
| Cr | 0.05-0.25 |
| Fe | ≤0.40 |
| Note: Single≤0.05; Total≤0.15 | |
Mechanical properties of 5083 marine grade aluminum plate sheet
| Alloy | Temper | Thickness ｍｍ | Tensile Strength RｍMPa | Specified non-proportional tensile strength Rp0.2 Mpa | Elongation％ | |
| A50 ｍｍ | A | |||||
| 5083 | O | 3.00-50.00 | 275-350 | ≥125 | ≥16 | ≥14 |
| H111 | 3.00-50.00 | 275-350 | ≥125 | ≥16 | ≥14 | |
| H22, H32 | 3.00-6.00 | 305-380 | ≥215 | ≥8 | - | |
| H116 | 3.00-50.00 | ≥305 | ≥215 | ≥10 | ≥10 | |
| H321 | 3.00-50.00 | 305-385 | ≥215 | ≥12 | ≥10 | |
| H112 | 6.00-50.00 | ≥275 | ≥125 | ≥12 | ≥10 | |
Marine Grade Aluminum 5083 of Haomei Aluminum
The 5083 aluminum alloy products used on board are usually available in different states to suit different application requirements. The following are some common 5083 aluminum alloy states and corresponding specifications :
Marine Grade Aluminum 5083 H116
The 5083 aluminum alloy in the H116 state is formed after stress working and stabilization treatment.
5083 h116 marine aluminum plate sheet has excellent corrosion resistance and crack resistance.
- Production Process: The 5083-H116 temper is achieved by applying controlled amounts of cold working and then undergoing a stabilization process.
- Corrosion Resistance: This temper is specifically designed for marine applications where high resistance to corrosion is essential. The H116 temper ensures that the material can withstand long-term exposure to seawater without significant degradation.
- Application : It is suitable for manufacturing ship structures such as hulls, decks, bulkheads, etc.
- Specifications : The thickness is between 1mm and 50mm, the width is between 1000mm and 1500mm, and the length is between 2000mm and 6000mm.
Marine Grade Aluminum 5083 H321
The 5083 aluminum alloy in the H321 state is a stable state formed after stress working and partial annealing.
5083 h321 marine aluminum plate sheet has excellent crack resistance and mechanical properties.
- Production Process: The 5083-H321 temper involves a slight thermal treatment following the work-hardening process. This treatment helps to stabilize the material and enhance its corrosion resistance.
- Corrosion Resistance: Similar to the H116 temper, 5083-H321 is also highly resistant to corrosion in marine environments. It can endure harsh underwater conditions, making it an excellent choice for similar applications.
- Application : Suitable for manufacturing high-speed ships, warships, submarines and other structures.
- Specifications : The thickness is between 1mm and 50mm, the width is between 1000mm and 1500mm, and the length is between 2000mm and 6000mm.
Marine Grade Aluminum 5083 H111
The 5083 aluminum alloy in the H111 state is an annealed state,
5083 h111 marine aluminum plate sheet has good plasticity and formability,
- Application : Suitable for manufacturing complex shaped parts and structures.
- Specifications : The thickness is between 1mm and 50mm, the width is between 1000mm and 1500mm, and the length is between 2000mm and 6000mm.
It should be noted that the specific specifications and conditions of 5083 aluminum alloy may vary depending on the supplier and application requirements. It is recommended to consult a professional or a reputable supplier or manufacturer for more detailed specification information when selecting a model.
Marine Grade Aluminum 5083 Manufacturer
Haomei Aluminum is a reputable ship plate supplier or manufacturer, The ship plate has complete specifications and huge production capacity, which can meet your individual processing needs.
5083 marine aluminum plate is a typical magnesium-aluminum-silicon alloy with stable performance, good corrosion resistance and durability in seawater, steam and other environments. The aluminum plate used for yachts has also passed the certification of DNV Det Norske Veritas to ensure that the quality of the 5083 ship plate meets the relevant standards and requirements.
The manufacturer has advanced production equipment and rich production experience to ensure that the quality of products meets customer satisfaction.
